Visaton Full-Range FRS8 - 4 Ohm 50 Watt 2003 Pakket

Visaton Full-Range FRS8 - 4 Ohm 50 Watt 2003 Pakket


8cm ( 3,3" ) HiFi Breedband Luidspreker - Visaton No. 2003



14.21

€ 12.90


Op voorraad


VISATON | Artikelcode: VI2003

Visaton Full-Range FRS8 - 4 Ohm 50 Watt 2003  Pakket


  • Productinformatie

8 cm (3.3") HiFi fullrange driver.
Linear frequency response between 200 and 20.000 Hz.
Suitable for surround effect speakers, mini sub/sat systems.
Due to the small size very suitable for model construction and as control speaker for electronic devices.

Typical applications:
- Control speaker for electronic devices
- Ceiling-mounted speakers in railway carriages and busses
- Mini Hi-fi systems
- Model construction


Technical Data:
Rated power 30 Watt
Maximum power 50 Watt
Nominal impedance 4 Ohm
Frequency response (-10 dB) 100 - 20000 Hz
Mean sound pressure level 82 dB (1W/1m)
Maximum cone displacement 5 mm
Resonance frequency fs 115 Hz
Magnetic induction 0,8 Tesla
Magnetic flux 200 µ Weber
Height of front pole-plate 4 mm
Voice coil diameter 2 cm
Height of winding 0,6 cm
Cutout diameter 7,3 cm
Net weight 0,28 kg
D.C. resistance Rdc 3,5 Ohm
Mechanical Q factor Qms 3,61
Electrical Q factor Qes 0,85
Total Q factor Qts 0,69
Equivalent volume Vas 1 l
Effective piston area Sd 31 cm2
Dynamically moved mass Mms 2,5 g
Force factor Bxl 2,2 T · m
Inductance of the voice coil L 0,43 mH
